Treasure Chests Pack - Animated Pixel Art [16/32/48/64px]

🧊 Made with Pixor: every sprite here was rendered from a 3D model, in every size and angle. Turn your own models into pixel art: try Pixor free in your browser or get it on itch.

Use these treasure chests in your pixel art projects!

Five chests that open and close, a mimic that bites, and the loot to go with them: every chest seen from 4 sides, in 4 sizes.

What's included:

- 8 pixel art items and their spritesheets (transparent png):

- 5 chests (wooden, iron, royal, cursed and frost), each with an Open (10 frames: the lid rattles, flies open and settles) and a Close animation (6 frames: it slams shut)

- 1 mimic chest with a Bite (6 frames) and an Idle animation (12 frames: it breathes, its lid lifting on its teeth)

- a coin pouch and a chest key with their rotating animation (24 frames)

- 4 sides for every chest in top-down: front, back, left and right, to place them against any wall!

- 4 sizes for each item: 16px, 32px, 48px & 64px!

- 2 angles for each item, for scroller (facing camera) & top-down (seen from above) games!

- 2 variants for each item, with & without outline, to match more art styles!

- 2 shades for each item, lit & unlit + 1 normal map, to use your own shading technique!

- a JSON file per chest sheet with every frame, animation and side (Aseprite format)

Every chest from every side, at 64px:

Every sheet of one chest, at 32px:

That's a total of 40 spritesheets per item, 320 in the pack!

Want only the wooden chest? It's free: https://frakassets.itch.io/free-wooden-chest

Need ores, ingots and wood to fill them? the Resource Drops Pack: https://frakassets.itch.io/resource-drops-pack

Made with Pixor

The sprites in this pack were made with Pixor, my tool that turns 3D models into animated pixel-art sprite sheets: every side, frame by frame, the same pixels every time. Pay once, offline.

Launch week: −30% until 11 October 2026 ($13.99 instead of $19.99).

Free browser demo, manual and 1,000+ free CC0 models: https://pixor.art/

How to use

1. Download the zip with the button above and unzip it. Each item has its own folder.

2. Pick a sheet: <item>_<size>_<angle>_<outline>_<shade>.png, for example wooden-chest_32px_top-down_outline_lit.png. Every frame is a square of its size (16, 32, 48 or 64 px). Play them at 12 frames per second.

A chest sheet has one row per animation and side: in top-down, Close South, East, North, West, then Open South, East, North, West (South is the front); in scroller, Close then Open. Open's last frame is the open chest and Close's last the closed one: hold either as a still. The mimic has Bite then Idle, in the same order. The coin pouch and the key are one row of 24 frames, looping. The .json beside each chest sheet lists every frame, animation and side.

3. Import it into your engine:

- Godot 4: import with Filter: Nearest (Project Settings → Rendering → Textures → Default Texture Filter). Add an AnimatedSprite2D, create SpriteFrames, click Add frames from sprite sheet, set Horizontal to the columns and Vertical to the rows, and pick one row per animation; 12 FPS. Open and Close don't loop; Bite, Idle and the turns do.

- Unity: Texture Type: Sprite (2D and UI), Sprite Mode: Multiple, Filter Mode: Point (no filter), Compression: None, Pixels Per Unit = the sheet's size. In the Sprite Editor: Slice → Grid By Cell Size (16, 32, 48 or 64). Drag one row's slices into the scene to make an animation; set it to 12 samples.

- GameMaker: Create Sprite → Import Strip Image, one row at a time (10 frames for Open, 6 for Close), size = the sheet's size, then set the sprite's speed to 12 frames per second.

- Aseprite: open the PNG with its .json beside it, or File → Import → Import Sprite Sheet, type By Rows, width and height = the sheet's size.

The normal maps (_normal.png) line up frame for frame with the sheets, for 2D lights (Godot CanvasTexture, Unity Secondary Textures → _NormalMap).

License: use these sprites in any number of projects, commercial or not, and change them as you like. Credit is appreciated but not required. You may not resell or redistribute the sprites as assets (on their own or in another asset pack), whether changed or not. Full terms in LICENSE.txt in the download.

You can directly include it in your game or use it as a framework to create new sprites!

Please rate and comment if you like it! <3
